Ultrapure Water Purification System Edi Water Treatment Process In Pharmaceutical CE
Product Details:
| Place of Origin: | China |
| Brand Name: | CHONGYANG |
| Certification: | ISO ,CE |
| Model Number: | CY-DROE-15000L/H |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | According to export standard |
| Delivery Time: | With 30-40 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 Sets/Month |
|
Detail Information |
|||
| Product Name: | Pharma Water System | Recovery Rate: | >97% |
|---|---|---|---|
| Connection: | Clamp ,Welding | Documentation: | DQ/IQ/OQ/PQ |
| Raw Water Source: | Purified Water Production | Material: | 316L Stainless Steel |
| Type: | Water Purification System | Warranty: | 1 Year |
| Highlight: | Pharmaceutical Edi Water Treatment Process,edi water treatment process CE,Stainless Steel Ultrapure Water Purification System |
||
Product Description
Product Name: Ultrapure Purified Water System In Pharmaceutical Industry CE Approval
Application Range:
Solvent or experimental water for pharmaceutical preparations .
A Solvent or diluent for oral and external preparation.
Cleaning Water for Wears used for Non Sterilizing Preparation.
Extraction Solvent for non sterilizing drugs .
A solvent and diluent for preparation of a injection.
Cleaning Water for vessel used for injection .
Solvent for eye drops.
Solvent for sterilized powder used for injection or diluent for injection
Typical Preparation Process:
The raw water ---The raw water pump ---Multi-media Filter---Activated Carbon Filter---Automatical softener device---Safe Filter---the first stage HP Pump---the first RO Device---The middle water tank---the second HP Pump---the second RO Device ---Pure Water Tank-- Water Pump---UV --Microporous Membrane Filter---the used water point (New Technology)
Technical Parameter:
| Output Water Capacity | 0.5m3/h--50m3/h |
| TOC | ＜100PPB |
| Conductivity | ＜0.5μs/cm |
| Microorganism | ＜100 CFU/ml |
| Endotoxin | ＜0.25EU/ml |
| Nitrate | ＜0.06PPM |
| Heavy metal | ＜0.1 PPM |
FAQ:
1.Questions: How to monitor water quatity of water treatment equipment ?
Answer : There are various instruments that used for test equipment at any time . Flow meter ,conductivity meter ,resistivity meter,pressure guage etc .
2. Questions:Is the purified water system full automatical operation ?
Answer : Yes. The USP grade purified water generation system have configurated PLC +HIM
3. How long is the Guarantee Peroid ?
Answer : One year .
